Description
x- High-frequency beam-former to ensure best resolution of the image
- 8steps for TGC and digital over-all Gain grasp the high-quality image
- Whole-course real-time continuous dynamic focusing and aperture obtains high-resolution and picture in picture in
- Super professional software packages to have the scanner widely used in Obstetrics Gynecoloyg,Urology, Cardiology ,Small parts.
- Easy for operators with the comfortable application and professional software package.
- It is the best choice for clinical diagnosis,because it makes clinic diagnostic more convenient and effective.
Description:
Specification For Ultrasound Scanner:
|
Screen Size |
10.4 inch |
|
Display Mode |
B, B+B, B+M, M, 4B |
|
Image gray scale |
256 scale |
|
Cine loop |
≥500 Frame |
|
Image storage |
64 Frame |
|
Scale Angle |
Adjustable |
|
Scan depth |
40mm~240mm |
|
Image flip |
Up/down,left/right,black/white |
|
Image Process |
GAMA,Image Smoothen.THI,Histogram,Zoom |
|
Focus |
Focus Number,Focus position,Focus space |
|
Measure |
Distance,circumference,area,volume,heart,GAFW,EDD |
|
Character display |
Date,clock,name,PID,age,sex,hospital name,doctor |
|
Output report |
4 types |
|
USB port |
USB2.0 |
|
Power consumption |
200VA |
|
Size |
1220mm×665mm×468mm |
Packing list:
1×Main Unit
1×3.5MHZ convex probe
1×Lilon battery
1×Power adapter(AC110V~240V,2A,50/60Hz)
1×Operation Manual
